DoR-L39 |
DoR-L48 |
DoR-L59 |
|
Pixel Pitch
|
3.91 mm |
4.81 mm |
5.95 mm |
|
Pixel Density
|
65,536 pixels/㎡ |
43,264 pixels/㎡ |
28,2244 pixels/㎡ |
|
LED Type
|
SMD 1921, 3 in 1 |
SMD 2525, 3 in 1 |
SMD 2525, 3 in 1 |
|
Module Size
|
250 x 250 mm |
||
|
Panel Size
|
500 x 400 mm |
||
|
Panel Resolution
|
128p x 128p |
104p x 104p |
84p x 84p |
|
Panel Type
|
Die-Casting Aluminum |
||
|
Panel Weight
|
9 KG/panel |
9 KG/panel |
9 KG/panel |
|
Power Consumption Max
|
680 W/㎡ |
680 W/㎡ |
650 W/㎡ |
|
Power Consumption Average
|
210 W/㎡ |
210 W/㎡ |
195 W/㎡ |
|
Driving Mode
|
1/16 |
1/13 |
1/7 |
|
Color Depth (bit)
|
14 bit |
||
|
Brightness
|
≥ 5000 nits |
≥ 5000 nits |
≥ 5000 nits |
|
Optimal Minimum View Distance
|
3.9 meters |
4.8 meters |
5.9 meters |
|
Refresh Rate
|
≥ 1920 Htz |
||
|
View Angle
|
H 160° / V 160° |
||
|
Power Input
|
AC 110/220, ±10%, 50/60 Htz |
||
|
Operation Humidity
|
10% - 90% RH |
||
|
Operation Temperature
|
-30 ~ 60 ℃ |
||
|
Ingress Protection
|
Front IP65 / Rear IP54 |
||
|
Service Type
|
Rear |
||
 |
