iGlass-3978 |
iGlass-7878 |
iGlass1010 |
|
Pixel Pitch
|
3.9x7.8 mm |
7.8x7.8 mm |
10.4x10.4 mm |
|
Pixel Density
|
32,768 pixels/㎡ |
16,384 pixels/㎡ |
9,216 pixels/㎡ |
|
LED Type
|
SMD 1921, 3 in 1 |
SMD 2525, 3 in 1 |
SMD 3535, 3 in 1 |
|
Transparency
|
85% |
75% |
60% |
|
Panel Size
|
1000 x 500 mm |
||
|
Panel Resolution
|
256p x 64p |
128p x 64p |
96p x 48p |
|
Panel Weight
|
15 KG/㎡ |
15 KG/㎡ |
15 KG/㎡ |
|
Power Consumption Max
|
1000 W/㎡ |
800 W/㎡ |
800 W/㎡ |
|
Power Consumption Average
|
300 W/㎡ |
240 W/㎡ |
240 W/㎡ |
|
Driving Mode
|
1/4 |
1/2 |
1/2 |
|
Color Depth (bit)
|
14 bit |
||
|
Brightness
|
≥ 4500 nits |
≥ 4500 nits |
≥ 4500 nits |
|
Optimal Minimum View Distance
|
3.9 meters |
7.8 meters |
10.4 meters |
|
Refresh Rate
|
≥ 1920 Htz |
||
|
View Angle
|
H 160° / V 160° |
||
|
Power Input
|
AC 110/220, ±10%, 50/60 Htz |
||
|
Operation Humidity
|
10% - 90% RH |
||
|
Operation Temperature
|
-30 ~ 60 ℃ |
||
|
Ingress Protection
|
IP42 |
||
 |
