Features



●     Ultra high definition for a tremendous 4K display;

●     High stability & reliability, High efficiency service;

●     Serialization design to be compatible with a variety of pixels;

●     Standard module size 240*240mm and panel size 480*480mm for all pixels available;

●     Visible control box and tool-free for control box;

●     Front & rear installation & maintenance;

●     Die-casting aluminum cabinet with seamless splicing for high precision connection;



Application

Conference room, TV Studio, Corporate, CCTV monitoring screen, Shopping mall, etc.


Specification

Model	HD-C18	HD-C20	HD-C25
Pixel Pitch	1.875 mm	2.0 mm	2.5 mm
Pixel Density	284,444 pixels/㎡	250,000 pixels/㎡	160,000 pixels/㎡
LED Type	SMD 1515, 3 in 1
Module Size	240 x 240 mm
Panel Size	480 x 480 x 65 mm
Panel Resolution	256p x 256p	240p x 240p	192p x 192p
Panel Type	Die-Casting Aluminum
Panel Weight	6 KG/panel	6 KG/panel	6 KG/panel
Power Consumption-Max	565 W/㎡	550 W/㎡	520 W/㎡
Power Consumption-Ave.	170 W/㎡	165 W/㎡	156 W/㎡
Driving Mode	1/32	1/30	1/32
Brightness	≥ 900 nits	≥ 900 nits	≥ 900 nits
Optimal Mini View Distance	1.8 meters	2 meters	2.5 meters
Refresh Rate	≥ 1920 Htz
View Angle	H 160° / V 160°
Power Input	AC 110/220, ±10%, 50/60 Htz
Operation Humidity	10% - 90% RH
Operation Temperature	-30 ~ 60 ℃
Service Type	Front & Rear
