Features



●     High definition display with super fine pixel pitch;

●     Front service design brings to fast and easy maintenance;

●     High refresh rate makes better image quality in cameras;

●     Slim cabinet design saves packing space and shipping cost;





 Application

Conference room, TV Studio, Corporate, CCTV monitoring screen, Shopping mall, etc.

 Specification

Model No.	UHD64-12	UHD64-15	UHD64-18	UHD64-25
Pixel Pitch (mm)	1.2	1.5	1.8	2.5
Pixel Density	640,000	403,225	284,089	160,000
LED Type	SMD 3 in 1
View Angle	H:140  V:140
Brightness	≥800nits
Driving Mode	1/32	1/52	1/43	1/16
Refresh Rate	≥3840 Htz
Mini. View Distance	1.2 Meter	1.5 Meter	1.8 Meter	2.5 Meter
Module Size (mm)	320 x 160 mm
Module Matrix (dot)	256*128	208*104	172*86	128*64
Panel Size (mm)	640 x 480mm
Panel Matrix (dot)	512*384	416*312	344*258	256*192
Panel Material	Die-casting magnesium
Panel Weight	30 KG/sq.m
Ingress Protection	IP40
Access Direction	Front Service
Input Voltage	AC 110V / 220V, ±10%,   50/60Htz
Power Consump.-Max	800 W/sq.m
Power Consump.-Ave.	240 W/sq.m
Life Span	100,000 Hours
Operation Temperature	-20 ~ +50 Deg. Celsius
Operation Humidity	10%~90%, No condensation
Operation System	Windows (/XP/Vista/7/8/10)
