SiF-4 |
SiF-5 |
SiF-6 |
|
Pixel Pitch
|
4 mm |
5 mm |
6 mm |
|
Pixel Density
|
62,500 pixels/㎡ |
40,000 pixels/㎡ |
27,777 pixels/㎡ |
|
LED Type
|
SMD 3 in 1, 1R1G1B |
SMD 3 in 1, 1R1G1B |
SMD 3 in 1, 1R1G1B |
|
Module Size
|
256 x 128 mm |
320 x 160 mm |
192 x 192 mm |
|
Panel Size
|
768 x 768 mm |
960 x 960 mm |
768 x 768 mm |
|
Panel Resolution
|
192p x 192p |
192p x 192p |
128p x 128p |
|
Power Consumption Max
|
680 W/㎡ |
650 W/㎡ |
680 W/㎡ |
|
Power Consumption Average
|
204 W/㎡ |
195 W/㎡ |
204 W/㎡ |
|
Driving Mode
|
1/8 |
1/8 |
1/8 |
|
Brightness
|
≥ 1200 nits |
≥ 1200 nits |
≥ 1500 nits |
|
Optimal Minimum View Distance
|
4 meters |
5 meters |
6 meters |
|
Refresh Rate
|
≥ 1920 Htz |
||
|
View Angle
|
H 140° / V 140° |
||
|
Power Input
|
AC 110/220, ±10%, 50/60 Htz |
||
|
Operation Humidity
|
10% - 90% RH |
||
|
Operation Temperature
|
-20 ~ 50 ℃ |
||
|
Ingress Protection
|
IP30 |
||
|
Service Type
|
Front / Rear |
||
 |
