SoF4 |
SoF5 |
SoF6 |
SoF8 |
SoF10 |
|
Pixel Pitch |
4mm |
5mm |
6mm |
8mm |
10mm |
|
Pixel Density |
62,500 pixels/㎡ |
40,000 pixels/㎡ |
27,777 pixels/㎡ |
15,625 pixels/㎡ |
10,000 pixels/㎡ |
|
LED Type |
SMD 3 in 1, 1R1G1B |
SMD 3 in 1, 1R1G1B |
SMD 3 in 1, 1R1G1B |
SMD 3 in 1, 1R1G1B |
SMD 3 in 1, 1R1G1B |
|
Module Size |
256x128mm |
160x160mm |
192x192mm |
256x128mm |
160x160mm |
|
Panel Size |
1024x768mm |
960x960mm |
768x768mm |
1024x768mm |
960x960mm |
|
Panel Resolution |
256p x 192p |
192p x 192p |
128p x 128p |
128p x 96p |
96p x 96p |
|
Power Consumption Max
|
780 W/㎡ |
665 W/㎡ |
750 W/㎡ |
685 W/㎡ |
540 W/㎡ |
|
Power Consumption Average
|
312 W/㎡ |
266 W/㎡ |
300 W/㎡ |
274 W/㎡ |
216W/㎡ |
|
Driving Mode
|
1/8 |
1/8 |
1/8 |
1/4 |
1/4 |
|
Brightness
|
≥5000 nits |
≥5000 nits |
≥5500 nits |
≥5500 nits |
≥5500 nits |
|
Optimal Minimum View Distance
|
4 meters |
5 meters |
6 meters |
8 meters |
10 meters |
|
Refresh Rate
|
≥ 1920Htz |
||||
|
View Angle
|
H 140° / V 140° |
||||
|
Power Input
|
AC 110V/220V, ±10%, 50/60Htz |
||||
|
Operation Humidity
|
10% - 90% RH |
||||
|
Operation Temperature
|
-30 ~ 60 ℃ |
||||
|
Ingress Protection
|
Front IP65 / Rear IP54 |
||||
|
Service Type |
Rear |
||||
 |
